Description
This 12.1″ colour TFT LCD industrial monitor replaces the colour 14″ CRT displays that are fitted to Fagor 8050 and Fagor SL/861432002 controllers. Note: a 12.1″ TFT LCD display provides the same active display area as a 14″ CRT.
It is a drop-in replacement that is fully compatible, both mechanically and electrically. Simply remove the old monitor and fit the new LCD monitor. There is no need for modifications. The video connection is by either a 9/15/25 pin D-sub connector or 5 x BNC connectors. It is powered by 85-240 VAC via the on-board IEC (kettle type) power connector. A re-wirable IEC connector is provided with the monitor.
Technical details of our replacement Fagor SL/861432002 monitor
New Display: 12.1″ TFT LCD colour, 800 x 600 pixels
Compatible with: Fagor 8050 and Fagor SL/861432002 controller
Replacement for: 14″ colour CRT CC14MSY1-A349, TOI12LB1-A618 / 26S14M35H
Connector on monitor: 9/15/25 pin D-sub connector or 5 x BNC
Housing: fully compatible
Settings: via OSD (On Screen Display)
Operating Voltage: 85-240 VAC
Manufacturing: Made in Germany. CE industry standard, EN55022, EN55024.
Warranty: 2 years
Our Part Number: LCD12-0183
| Request for LCD12-0183 |
Availability
Please contact our sales team by phone or email for delivery options
How To Order Your Replacement Monitor
Call us on +44 (0) 1438 362897 or Email.
We accept BACS payments and Credit/Debit cards
